Complete skydomes

Complete skydomes

Circular, square and rectangle based rooflight domes with 1-2-3 or 4 layers, with optional manual or automatic opening system and collars, in transparent or opal colour, made of polycarbonate or PMMA.

Tovább olvasom



Plasticor heat-insulating skydomes



The skydomes - mostly on flat roofs – provides solid light in bigger spaces, where the standard windows cannot provide enough for the whole room. Thanks to the shaping, the material and equipment use, the presences of the domes are aesthetic, and have a perfect heat-insulation.



Variations to a task



The fix skydomes provide natural light without the daily ventilation feature. The fix domes cannot be opened by hand, moreover, the specially manufactured high impact polycarbonate “armor domes” even whitstands burglary! The electric or manually opened skydomes provide optimal amount of natural light, and the variable opening height enables the comfortable daily ventilation without draft. The Plasticor rooflight domes can be ordered with escape hatches too, which enables the easy and comfortable access to the roof, while providing the same amount of natural light.

The Plasticor skydomes can be ordered in huge variety. Not only the dimensions, but the used materials are important part of the complete order too. The collars can be made of:

  • PVC
  • Fibre glass polyester
  • Galvanized steel with outer thermal insulation

The height of the PVC collars are always 15 cm, the fibre glass, and the galvanized steel collars can be 15, 30 and 50 cm high. The waterinsulation can be fitted with flame on the polyester and the galvanized steel collars.

The transparent layers can be made of:

  • polycarbonate (PC)
  • acryl (PMMA)

The polycarbonate layers are unbreakable, with a fire rating of B-s1, d0. The acryl (PMMA) layers have much better weather resistance, and keep their original colour longer.

The dome layers can be ordered in the following colours:

  • clear
  • white (opal)
  • outer layer white (opal), inner layer(s) clear
  • Heatstop
  • Solar control IR
  • any other from the manufacturer’s range of colours

The transparent layers let through the most light, therefore the most heat too. The opal layers provide pleasant diffused light, so we advise to use it in living spaces or places of work.

The left picture below shows a transparent layered rooflight dome, while the right one shows an opal layered one. Although the amount of light projected are equal, in case of the opal coloured layers the shadows are not so contrasty, the corners become brighter, and therefore the space becomes more pleasing.

If you wish to learn more about the layers, and their colours, please visit our sub-site.





Available dimensions



When designing a skydome, usually the most basic dimension is the "B", as the size of the roof opening. Size "A" is the size of the transparent surface. Size "C", "E" or "D" usually needed when replacing an extant dome or when building a special/unique collar.

Square shaped skydomes
B size A size C size 1 layered 2 layered 3 layered 4 layered 5 layered
roof opening
[cm]		 skydome size
[cm]		 layers outer dimension
[cm]
PVC collars
15 cm		 polyester collars
15; 30; 50 cm
65×65 60×60 40×40 56×56 • • • • •
75×75 70×70 50×50 66×66 • • • • •
85×85 80×80 60×60 76×76 • • • • •
95×95 90×90 70×70 86×86 • • • • •
100×100 95×95 75×75 91×91 • • • • •
105×105 100×100 80×80 96×96 • • • • •
115×115 110×110 90×90 106×106 • • • • •
125×125 120×120 100×100 116×116 • • • • •
145×145 140×140 120×120 136×136 • • • • •
155×155 150×150 130×130 146×146 • • • • •
165×165 160×160 140×140 156×156 • • • • •
175×175 170×170 150×150 166×166 • • • • •
185×185 180×180 160×160 176×176 • • • • •
205×205 200×200 180×180 196×196 • • • • •
225×225 220×220 200×200* 216×216 • • • • -

* The A=200×200 cm sized skydomes can be ordered with acrylic layers only!


Rectangular shaped skydomes
B size A size C size 1 layered 2 layered 3 layered 4 layered 5 layered
roof opening
[cm]		 skydome size
[cm]		 layers outer dimension
[cm]
PVC collars
15 cm		 polyester collars
15; 30; 50 cm
- 50×100 30×80 46×96 • • • • •
65×95 60×90 40×70 56×86 • • • • •
- 60×100 40×80 56×96 • • • • •
65×125 60×120 40×100 56×116 • • • • •
85×115 80×110 60×90 76×106 • • • • •
85×175 80×170 60×150 76×166 • • • • •
85×225 80×220 60×200 76×216 • • • • •
- - 60×230 76×246 • • • • •
95×125 90×120 70×100 86×116 • • • • •
- - 71×106 87×122 • • • • •
100×145 95×140 75×120 91×136 • • • • •
100×150 - 75×125 91×141 • • • • •
100×200 - 75×175 91×191 • • • • •
- 95×140 76×121 92×137 • • • • •
- 100×120 80×100 96×116 • • • • •
- 100×145 80×125 96×141 • • • • •
105×155 100×150 80×130 96×146 • • • • •
105×205 100×200 80×180 96×196 • • • • •
- 100×250 80×230 96×246 • • • • •
- 100×300 80×280 96×296 • • • • •
115×145 110×140 90×120 106×136 • • • • •
115×175 110×170 90×150 106×166 • • • • •
125×155 120×150 100×130 116×146 • • • • •
125×175 120×170 100×150 116×166 • • • • •
125×185 120×180 100×160 116×176 • • • • •
125×225 120×220 100×200 116×216 • • • • •
125×245 120×240 100×220 116×236 • • • • •
- 120×250 100×230 116×246 • • • • •
- 120×270 100×250 116×266 • • • • •
145×175 140×170 120×150 136×166 • • • • •
145×205 140×200 120×180 136×196 • • • • •
145×235 140×230 120×210 136×226 • • • • •
155×185 150×180 130×160 146×176 • • • • •
155×205 - 130×180 146×196 • • • • •
155×215 150×210 130×190 146×206 • • • • •
155×245 150×240 130×220 146×236 • • • • •
- 150×250 130×230 146×246 • • • • •
155×275 150×270 130×250 146×266 • • • • •
- 180×210 160×190 176×206 • • • • •
185×245 180×240 160×220 176×236 • • • • •
- 180×250 160×230 176×246 • • • • •
185×275 180×270 160×250 176×266 • • • • •
185×305 180×300 160×280 176×296 • • • • •
- - 180×240 196×256 • • • • •


Circular shaped skydomes
B size A size C size 1 layered 2 layered 3 layered 4 layered 5 layered
roof opening
[cm]		 skydome size
[cm]		 layers outer dimension
[cm]
PVC collars
15 cm		 polyester collars
15; 30; 50 cm
ø65   ø60 Ø40  ø56 • • • • •
ø75 ø70 Ø50 ø66 • • • • •
ø85 ø80 Ø60 ø76 • • • • •
ø95 ø90 Ø70 ø86 • • • • •
ø105 ø100 Ø80 ø96 • • • • •
ø115 - Ø90 ø106 • • • • •
ø125 ø120 Ø100 ø116 • • • • •
ø145 - Ø120 ø136 • • • • •
ø155 ø150 Ø130 ø146 • • • • •
- - Ø140 ø156 • • • • •
- - Ø150 ø166 • • • • •
ø185 ø180 Ø160 ø176 • • • • •
- ø200 Ø180 ø196 • • • • •
- ø220 Ø200* ø216 • • • • -

* The A=Ø200 cm sized skydomes can be ordered with acrylic layers only!
